Hydrant Pit Cleaner
Removes contaminated fuel and cleans and dries the hydrant system, with vacuum, water and air pumps in one vehicle.
- Tank capacity
- 1,000-10,000 L
- Cleaning system
- Hydraulic-driven vacuum / fuel / water pumps
Technical drawing
Where the main equipment sits on the hydrant pit cleaner, on one fuel line.
01 / 08Standard fit
Spring rewind reel drive
Specification
Each unit is configured per order to the customer’s operation.
| ACapacity | |
|---|---|
| Tank capacity | 1,000-10,000 L |
| BPerformance | |
| Cleaning system | Hydraulic-driven vacuum / fuel / water pumps |
| Drying | Dry air reservoir |
| CCompliance | |
| Built to |
|
| DPer order | |
| Chassis make and model | Confirmed in the quotation |
| Dimensions and weights | Confirmed in the quotation |
| Component makes and models | Confirmed in the quotation |
Equipment
Standard fit on every unit, with options configured per order.
Standard
08- 01Aluminium or stainless steel tank
- 02Water tank compartment
- 03Vacuum drain compartment system
- 04Low-point flushing tank compartment
- 05Dry air reservoir
- 06Spring rewind reel drive
- 07Close-circuit sampling system
- 08Drive-away interlock system
Options
03- 01Stainless steel / aluminium flow system piping
- 02Hydraulic lift crane
- 03Additional hydrant coupler stowage
Available as options, configured per order.
Photographs
Photographs and stills from the MATEŞ film. Select one to enlarge.
10 photographs
